BLACKMAGIC 5" scherm 1920 x 1080, Video Assist 10-bit 4:2:2 1080p tot 60fps recorder

€ 534,00

€ 441,32 exclusief BTW
Artikelnummer
BMVAS
Voorraad
Niet op voorraad


Omschrijving

Dual 8" LCD Monitors

Large color LCD monitors with high quality video filtering for amazing images.


Monitor 2 SDI In with Loop Out

SDI/HD-SDI and 3 Gb/s SDI input connection for decks, routers or cameras in 10 bit  SD, HD or even 2K.


Tally Connection

Industry standard tally inputs for each monitor allows independent tally to display red, green or blue.


Ethernet In with Loop Out

Control all your monitors from a single computer for easy matching between displays!


USB 2.0 Update Port

Update your SmartView Duo software to add new video formats as they are invented!


International Power Supply

Standard 12V power supply with international adapters for connection to all power outlets. Cable tie down point.


Monitor 1 SDI In with Loop Out

SDI/HD-SDI and 3 Gb/s SDI input connection for decks, routers or cameras in 10 bit  SD, HD or even 2K.


Tally Connector Info

Forget reaching for the instruction manual, because the Tally connections are listed here!



SmartView Duo

SmartView HD

Connections
SDI Video Input Switchable between SD, HD and 3 Gb/s SDI. Reclocked loop through output. Switchable between SD, HD and 3 Gb/s SDI. Reclocked loop through output.
Multi Rate Support Auto detection of 2K, HD or standard definition inputs Auto detection of 2K, HD or standard definition inputs
Updates and Configuration Via USB 2.0 high speed (480 Mb/s) Via USB 2.0 high speed (480 Mb/s)
Ethernet 10/100 BaseT with loop through. 10/100 BaseT with loop through.
Tally 9-pin D connector 9-pin D connector
Standards
SDI Compliance SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M and SMPTE 425M SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M and SMPTE 425M
SDI Color Space REC 601, REC 709 REC 601, REC 709
SDI Auto Switching Automatically selects between SD, HD and 3 Gb/s SDI Automatically selects between SD, HD and 3 Gb/s SDI
Video Sampling 4:2:2 and 4:4:4 4:2:2 and 4:4:4
SDI Format Support 525i59.94, 625i50, 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080PsF23.98,1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080p23.98, 1080p24, 1080p25, 1080p29.97,1080p30, 1080p50, 1080p59.94, 1080p60, 2048x1080p/23.98, 2048x1080p/24, 2048x1080p/25,2048x1080PsF/23.98, 2048x1080PsF/24, 2048x1080PsF/25, 2048x1556PsF/23.98, 2048x1556PsF/24,2048x1556PsF/25 525i59.94, 625i50, 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080PsF23.98,1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080p23.98, 1080p24, 1080p25, 1080p29.97,1080p30, 1080p50, 1080p59.94, 1080p60, 2048x1080p/23.98, 2048x1080p/24, 2048x1080p/25,2048x1080PsF/23.98, 2048x1080PsF/24, 2048x1080PsF/25, 2048x1556PsF/23.98, 2048x1556PsF/24,2048x1556PsF/25
Extras
Software Control Mac OS X™ and Windows™ Mac OS X™ and Windows™
Internal Software Upgrade Via included firmware updater software Via included firmware updater software
Settings Control Via USB or Ethernet Via USB or Ethernet
Rack Height 3 Rack Units 6 Rack Units
Displays 2 1
Display Size 8" diagonal 17.3" diagonal
Display Element TFT Active Matrix LCD TFT Active Matrix LCD
Display Resolution 800 x 480 pixels 1920 x 1080 pixels
Response < 15 ms < 12 ms
Contrast Ratio Typically 500:1 Typically 650:1
Color Depth 16.7 Million Colors 262,144 Colors
Display Orientation Displays can rotate upside down for optimum viewing angle Displays can rotate upside down for optimum viewing angle
Power Supply 12V universal power supply included with international socket adapters for all countries 12V universal power supply included with international socket adapters for all countries
Power Consumption < 20 Watts < 20 Watts
Operational Voltage Range 12V - 15V 12V - 15V
Technische specificaties
Merk Blackmagic Design
